Conveyor Belt
Adhesion-ply to ply
|
Index |
Canvas ply to canvas ply |
Cover to belt core |
|
|
cover thickness |
|||
|
0.8-1.5mm |
＞1.5mm |
||
|
average value of samplesN/mm≥ |
3.2 |
2.1 |
2.7 |
|
bottom value of samples |
2.7 |
1.6 |
2.2 |
|
Remark: The bottom value of sample can not surpass 20N/mm |
|||
|
According to GB/T7984-2001 Conveyor Belt---Conveyor Belt with rubber or plastic cover used for general usage standard |
|||
Types and Specification
|
Type |
Fabric |
Width mm |
Applications |
|
General conveyor belt |
T/C or CC |
300～2000 |
For materials of lump, granular, powdery or finished products under general conditions. |
|
NN conveyor belt |
NN100 |
For materials of heavy duty and high impact conveying in medium and long distance |
|
|
NN150 |
|||
|
NN200 |
|||
|
NN250 |
|||
|
NN300 |
|||
|
EP conveyor belt |
EP100 |
For materials in harsh conveying conditions like medium or long distance, heavy load, humid environment and high temperature. |
|
|
EP150 |
|||
|
EP200 |
|||
|
EP250 |
|||
|
EP300 |
|||
|
Heat resistant conveyor belt |
EP, T/C, CC |
80℃，125℃150℃ |
|
|
Oil resistant conveyor belt |
NN, EP, T/C, CC etc. |
For general oily materials |
|
|
Acid and Alkali resistant conveyor belt |
For materials with chemical medicine, chemicals, paper pulp and fertilizer etc. |
||
|
Chevron conveyor belt |
500、650、800、1000 |
For conveying in steep angel. Heat resistant, oil resistant, acid and alkali resistant chevron belt are available for handling different materials. |
Remark: Special size belts can be made as customer's requested
-----------------------------------------------------------------------------------------------------------
